POLY BRAID
Flexible Silicone Insulated with Polyester Braid
Cable is typically used in control panels where high temperatures often resinate. The cable maybe connected directly and permanently to a coil winding, motor or other components of electrical devices.
SPECIFICATIONS
| Nominal Voltage: | 1.5kV |
| Maximum Operating Temp.: | +180oC |
| Minimum Operating Temp.: | -60oC |
| Maxmium Short Circuit Temp: | 350oC on the conductor |
| Minimum Bending Radius: | Fixed: 4 X ODmax |
- Conductor: Flame Resistant flexible copper class 5
- Insulation: Silicone Rubber
- Sheath:Polyester Braid
- Sheath Colour: Orange
- Fire: EN 60754-1/2,EN 61034-1/2,EN60332-1-2
- EN 50363 IEC EN 60228
SOLD IN FULL DRUMS OR CUT TO SIZE
Orders supplied in full drums or cut to your specification at NO extra cost
